the role of CFR-50JB-52-1K1 products in practical applications
CFR-50JB-52-1K1 products are carbon film resistors with a resistance of 1.1 kOhms and a power rating of 0.5W. These resistors ensure precision and reliability in demanding environments. Their global market, valued at USD 1.5 billion in 2023, is growing due to rising demand in electronics and automotive industries.
| Characteristic | Value |
|---|---|
| Operating Temperature | -55°C ~ 155°C |
| Tolerance | ±5% |
| Temperature Coefficient | -500/ +350ppm/°C |
| Power (Watts) | 0.5W, 1/2W |
| RoHS Status | ROHS3 Compliant |
The role of CFR-50JB-52-1K1 in these industries highlights their importance in meeting modern technological needs.
Key Takeaways
- CFR-50JB-52-1K1 resistors provide exact resistance of 1.1 kOhms. They can handle up to 0.5W of power, making them useful in many devices.
- These resistors work well in very hot or cold places. They can handle temperatures from -55°C to 155°C, staying stable and reliable.
- Their small size and shape make them easy to fit in tight spaces. This helps improve how electronic systems work.
Overview of CFR-50JB-52-1K1 Products
Key Features and Specifications
CFR-50JB-52-1K1 resistors stand out due to their precise specifications. These carbon film resistors offer a resistance value of 1.1 kOhms and a power rating of 0.5W, making them suitable for various applications. You can rely on their ±5% tolerance, ensuring consistent performance even in demanding environments. Their temperature coefficient ranges from -500 to +350 ppm/°C, which helps maintain stability across a wide temperature range.
Here’s a quick overview of their specifications:
| Product Attribute | Attribute Value |
|---|---|
| Resistance | 1.1 kOhms |
| Power Rating | 0.5W (1/2W) |
| Tolerance | ±5% |
| Temperature Coefficient | -500/+350 ppm/°C |
| Operating Temperature | -55°C to 155°C |
| Size / Dimension | 0.130" Dia x 0.354" L |
| RoHS Compliance | ROHS3 Compliant |
These features make CFR-50JB-52-1K1 resistors a reliable choice for precision-driven applications.
Unique Characteristics and Design
The design of CFR-50JB-52-1K1 resistors reflects their focus on durability and efficiency. Manufactured by Yageo, these resistors use a carbon film composition, which ensures excellent electrical performance. Their axial package design simplifies integration into circuits, while the compact size (0.130" diameter and 0.354" length) saves space in electronic assemblies.
Another key feature is their ability to operate in extreme temperatures, from -55°C to 155°C. This makes them ideal for environments where temperature fluctuations are common. With two terminations, these resistors ensure secure connections in your circuits. Additionally, their compliance with ROHS3 standards highlights their environmentally friendly design.
| Feature | Specification |
|---|---|
| Composition | Carbon Film |
| Package Type | Axial |
| Number of Terminations | 2 |
| Manufacturer | Yageo |
| Operating Temperature | -55°C to 155°C |
These unique characteristics set CFR-50JB-52-1K1 apart from other resistors, ensuring they meet your performance and design needs.
Role of CFR-50JB-52-1K1 in Practical Applications
Use in Electronics and Circuit Design
CFR-50JB-52-1K1 resistors play a critical role in electronics and circuit design. Their precise resistance value and durability make them essential for maintaining stability in various devices. You will find these resistors in computers, televisions, and smartphones. They help regulate current flow, ensuring that circuits operate efficiently and safely. Their compact size also allows you to integrate them into space-constrained designs without compromising performance.
In industrial equipment, these resistors contribute to reliable operation under demanding conditions. Their ability to withstand high temperatures ensures consistent performance, even in environments with significant heat generation. By using CFR-50JB-52-1K1 resistors, you can enhance the reliability and longevity of your electronic systems.
Applications in Automotive Systems
The automotive industry relies heavily on the role of CFR-50JB-52-1K1 resistors. These components are vital in systems like engine control units, lighting circuits, and infotainment systems. Their ability to handle temperature extremes makes them ideal for vehicles operating in diverse climates. You can depend on these resistors to maintain precision in sensitive automotive circuits, ensuring safety and performance.
In electric vehicles, CFR-50JB-52-1K1 resistors help manage power distribution and protect critical components. Their durability and compliance with environmental standards make them a sustainable choice for modern automotive designs.
Role in Medical Diagnostic Equipment
Medical diagnostic equipment demands high precision and reliability. CFR-50JB-52-1K1 resistors meet these requirements by providing stable resistance values and excellent temperature tolerance. You will find them in devices like ECG machines, blood analyzers, and imaging systems. These resistors ensure accurate signal processing, which is crucial for delivering reliable diagnostic results.
Their compact design allows you to incorporate them into advanced medical devices without adding unnecessary bulk. By using CFR-50JB-52-1K1 resistors, you can enhance the performance and dependability of medical equipment, ultimately improving patient care.
Benefits and Challenges
Advantages of Reliability and Durability
You can rely on CFR-50JB-52-1K1 resistors for their exceptional reliability and durability. These resistors are designed to perform consistently, even in challenging environments. Their bulk construction protects against moisture and dust, ensuring long-term stability. The ability to resist temperature fluctuations enhances their reliability in applications where conditions vary significantly. Additionally, their longevity reduces the need for frequent replacements, saving you time and resources.
| Feature | Benefit |
|---|---|
| Bulk Construction | Protects against moisture and dust |
| Temperature Resistance | Ensures reliability under temperature fluctuations |
| Longevity | Increases overall durability of the component |
These features make CFR-50JB-52-1K1 resistors a dependable choice for critical systems.
Cost-Effectiveness and Efficiency
The efficiency of CFR-50JB-52-1K1 resistors directly impacts the performance of your systems. These resistors ensure reliable current limiting, effective voltage regulation, and precise signal conditioning. Their high-performance design maintains stability and accuracy, even under extreme environmental conditions. This efficiency not only enhances device longevity but also reduces operational costs over time.
- The efficiency of CFR-50JB-52-1K1 resistors ensures reliable current limiting.
- They contribute to effective voltage regulation.
- These resistors aid in signal conditioning across various electronic applications.
- High-performance design maintains stability and accuracy under different environmental conditions, enhancing device longevity and reliability.
By choosing these resistors, you can achieve both cost savings and improved system performance.
Limitations and Considerations for Use
While the role of CFR-50JB-52-1K1 resistors is significant, you should consider a few factors when integrating them into your designs. Environmental protection is crucial to ensure their longevity and reliability. You must also account for the operating temperature range to guarantee performance under various conditions. Paying attention to the resistor's composition and tolerance is essential for achieving accuracy in your applications. Lastly, their dimensions should align with your design constraints to ensure proper integration.
- Environmental protection is crucial for longevity and reliability.
- Consider the operating temperature range to ensure performance under various conditions.
- Pay attention to the resistor's composition and tolerance for accuracy in applications.
- Dimensions are important for fitting within design constraints.
By addressing these considerations, you can maximize the effectiveness of CFR-50JB-52-1K1 resistors in your projects.
CFR-50JB-52-1K1 resistors offer exceptional features that make them indispensable in modern technology. Their precise resistance, durability, and compact design support advancements in electronics, automotive systems, and medical devices.
| Product Attribute | Attribute Value |
|---|---|
| Manufacturer | Yageo |
| Resistance | 1.1 kOhms |
| Power (Watts) | 0.5W, 1/2W |
| Tolerance | ±5% |
| Temperature Coefficient | -500/ +350ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Composition | Carbon Film |
These resistors ensure accurate resistance adjustment and consistent performance. Their ability to withstand moisture and temperature fluctuations enhances reliability. You can depend on them for voltage regulation and current limiting, ensuring precision in critical systems. Across industries, CFR-50JB-52-1K1 products remain vital for achieving efficiency and reliability in demanding applications.
FAQ
What makes CFR-50JB-52-1K1 resistors suitable for extreme environments?
These resistors operate between -55°C and 155°C. Their carbon film composition and bulk construction protect against temperature fluctuations, moisture, and dust, ensuring durability in harsh conditions. 🌡️
Can you use CFR-50JB-52-1K1 resistors in compact designs?
Yes, their axial package and small size (0.130" diameter, 0.354" length) make them ideal for space-constrained electronic assemblies without compromising performance. 📏
Are CFR-50JB-52-1K1 resistors environmentally friendly?
Absolutely! These resistors comply with ROHS3 standards, ensuring they meet environmental safety requirements. You can use them confidently in sustainable designs. 🌍
