the product features of CFR-25JB-52-1K
When it comes to reliable electronic components, the CFR-25JB-52-1K stands out due to its impressive product features. Its carbon film construction ensures stability, while the lead-free, RoHS3-compliant design meets modern standards. With a precise 1kOhm resistance value and a wide operating temperature range (-55°C to 155°C), this resistor delivers consistent performance in demanding environments.
Key Takeaways
- The CFR-25JB-52-1K resistor gives a steady 1kOhm resistance. It has a ±5% tolerance, making it good for exact circuits.
- It works well in temperatures from -55°C to 155°C. This makes it useful in tough conditions and many applications.
- Its carbon film build and RoHS3 compliance make it strong. It is also eco-friendly and great for long-term use.
Technical Specifications of CFR-25JB-52-1K
Resistance Value and Tolerance
When you’re working with electronic circuits, precision matters. The CFR-25JB-52-1K offers a resistance value of 1K Ohm with a tolerance of ±5%. This means the resistor can vary slightly from its stated value, but only within a 5% range. Here’s a quick look:
| Resistance Value | Tolerance |
|---|---|
| 1K Ohm | ±5% |
Compared to similar products like the RC14JB47R0 and HHV-25JR-52-100K, the CFR-25JB-52-1K matches their ±5% tolerance, ensuring it’s just as reliable. This level of precision makes it a dependable choice for applications where accuracy is key.
Power Rating and Temperature Coefficient
The CFR-25JB-52-1K is built to handle a power rating of 0.25 W (1/4 W). This means it can safely dissipate a quarter watt of power without overheating. It also performs well across a wide temperature range, from -55°C to 155°C.
| Specification | Value |
|---|---|
| Power Rating | 0.25 W (1/4 W) |
| Operating Temperature Range | -55°C to 155°C |
| Temperature Coefficient | -350 to 500 ppm/°C |
The temperature coefficient, ranging from -350 to 500 ppm/°C, ensures the resistor maintains stability even when temperatures fluctuate. This is crucial for circuits that operate in varying environments.
Material Composition and Build Quality
The CFR-25JB-52-1K is crafted from carbon film, a material known for its stability and consistency. This composition ensures reliable performance in electronic applications. Plus, it’s lead-free and RoHS3 compliant, making it environmentally friendly. The resistor also meets certifications like ISO14001 and ISO9001, which validate its high-quality construction.
These product features make the CFR-25JB-52-1K a durable and trustworthy component for your projects. Whether you’re designing a simple circuit or a complex system, this resistor delivers the reliability you need.
Key Product Features
Durability and Longevity
When you’re choosing a resistor, durability matters. The CFR-25JB-52-1K is built to last, even in challenging environments. Its carbon film construction ensures it can handle wear and tear over time. Plus, it’s lead-free and RoHS3 compliant, so you know it meets strict environmental standards.
Here’s a quick breakdown of the features that contribute to its longevity:
| Feature | Description |
|---|---|
| Max Power Dissipation | 250mW, suitable for moderate power applications. |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited), allowing for unlimited storage and handling without special precautions. |
| Operating Temperature Range | -55°C to 155°C, ensuring broad temperature stability. |
| RoHS Status | ROHS3 Compliant, ensuring compliance with European Union regulations on hazardous substances. |
| Temperature Coefficient | -350/ +500 ppm/°C, providing stable performance across varying temperatures. |
These features make the CFR-25JB-52-1K a reliable choice for long-term use in electronic circuits.
Precision and Stability
You need a resistor that delivers consistent performance, and the CFR-25JB-52-1K does just that. Its carbon film composition ensures precise resistance control, making it ideal for circuits where accuracy is critical.
Here’s why it stands out:
| Feature | Specification |
|---|---|
| Composition | Carbon film |
| Operating Temperature Range | -55°C to 155°C |
| Temperature Coefficient | -350/ +500 ppm/°C |
| Moisture Sensitivity | Low |
| Compliance | RoHS3 |
This resistor has proven its stability in various applications, including automotive systems, industrial controls, and medical devices. It’s a dependable component for projects requiring precision and reliability.
Performance Across Temperature Ranges
Temperature changes can affect electronic components, but not the CFR-25JB-52-1K. It performs consistently across a wide range of temperatures, from -55°C to 155°C. This makes it suitable for environments with extreme conditions.
Here’s what ensures its stability:
| Specification | Value |
|---|---|
| Operating Temperature Range | -55°C to 155°C |
| Temperature Coefficient | -350/ +500 ppm/°C |
Its design ensures stable performance, even when temperatures fluctuate. Whether you’re working on industrial systems or automotive applications, this resistor won’t let you down.
Applications and Benefits
Common Use Cases in Electronics
You’ll find the CFR-25JB-52-1K in a variety of electronic applications. Its precise resistance and reliable performance make it a go-to choice for many projects. Here’s a quick look at where it shines:
| Application Type | Description |
|---|---|
| Microcontroller Boards | Used in projects requiring precise resistance values. |
| Sensor Modules | Necessary for accurate voltage division in signal processing. |
| Power Supply Units (PSUs) | Regulates output voltages in power supply units. |
Whether you’re working on a microcontroller project or designing a power supply, this resistor ensures your circuits perform as expected.
Advantages in Various Industries
The CFR-25JB-52-1K isn’t just for hobbyists. It’s a trusted component in industries like automotive, telecommunications, and medical devices. Its reliability and temperature stability make it indispensable.
| Advantage | Application Area |
|---|---|
| Reliability | Automotive Electronics |
| Temperature Stability | Automotive and Industrial Control |
| Compliance with Standards | Telecommunications and Medical |
For example, in automotive systems, it handles extreme temperatures without breaking a sweat. In medical devices, its precision ensures accurate readings. No matter the industry, this resistor delivers consistent results.
Cost-Effectiveness and Reliability
If you’re looking for a cost-effective solution, the CFR-25JB-52-1K is hard to beat. It combines affordability with top-notch performance. Here’s why manufacturers love it:
| Feature | Description |
|---|---|
| Reliable Performance | The resistor provides consistent performance across various applications. |
| Precise Resistance Control | It offers accurate resistance values, essential for high-quality electronic designs. |
| Compliance with Environmental Standards | The lead-free and RoHS3 compliant construction meets modern electronics requirements. |
| Suitable Applications | Ideal for general-purpose circuits requiring moderate power handling and precise control. |
This resistor’s product features make it a smart choice for anyone balancing performance and budget. You get reliability without overspending.
The CFR-25JB-52-1K packs a lot into a small package. Its 1kOhm resistance, 0.55 mm lead diameter, and 250mW power dissipation make it a dependable choice for your projects. You’ll appreciate its wide operating temperature range (-55°C to 155°C) and RoHS3 compliance, ensuring both performance and environmental safety.
Here’s why it stands out:
| Feature | Description |
|---|---|
| Resistance Value | 1kOhm, offering precise resistance control. |
| Max Power Dissipation | 250mW, suitable for moderate power applications. |
| Operating Temperature Range | -55°C to 155°C, ensuring broad temperature stability. |
| Lead Diameter | 0.55 mm |
| Temperature Coefficient | -350/ +500 ppm/°C, providing stable performance across varying temperatures. |
You can rely on this resistor for general-purpose circuits, automotive electronics, industrial control systems, and even medical devices. Its durability and precision make it a versatile and cost-effective solution for a wide range of applications.
FAQ
What makes the CFR-25JB-52-1K different from other resistors?
Its carbon film build ensures stability and precision. It’s RoHS3 compliant, durable, and performs well across a wide temperature range (-55°C to 155°C).
Tip: This resistor is perfect for projects needing reliability and environmental compliance.
Can I use the CFR-25JB-52-1K in high-temperature environments?
Yes! It works flawlessly in temperatures up to 155°C. Its temperature coefficient ensures stable performance even in extreme conditions.
Note: Always check your circuit’s power and temperature requirements before use.
Is the CFR-25JB-52-1K suitable for beginners?
Absolutely! Its 1kOhm resistance and ±5% tolerance make it beginner-friendly. You can use it in microcontroller projects, sensor modules, or basic circuits.
Emoji Tip: 🛠️ Start small and experiment with this reliable resistor in your DIY projects!
