CFR-50JB-52-1M product details
The CFR-50JB-52-1M, a carbon film resistor by YAGEO, plays a vital role in electronic circuits. You can rely on it to limit current, regulate voltage, and condition signals. Its high reliability and heat dissipation make it ideal for computers, televisions, and automotive systems, even in harsh environments.
Key Takeaways
- The CFR-50JB-52-1M is a strong carbon film resistor. It has a resistance of 1 MΩ and ±5% tolerance. This ensures steady performance in electronic circuits.
- This resistor works well in very hot or cold temperatures. It can handle from -55°C to +155°C. This makes it great for cars and industrial machines.
- Its tough design reduces noise and boosts reliability. This makes the CFR-50JB-52-1M perfect for accurate tasks and long use.
Specifications of the CFR-50JB-52-1M
Resistance value and tolerance
The CFR-50JB-52-1M offers a resistance value of 1 MΩ with a tolerance of ±5%. This level of precision ensures that your circuits maintain consistent performance, even under varying conditions. To help you compare, here’s a quick look at how this resistor stacks up against others in its category:
| Resistor Model | Resistance | Tolerance | Power Rating | Type |
|---|---|---|---|---|
| CFR-50JB-52-1M | 1 MΩ | ±5% | 0.5W | Carbon Film |
| CFR-12JB-52-10K | 10 kΩ | ±5% | 0.167W | Carbon Film |
| CFR-12JR-52-10K | 1 MΩ | ±5% | 0.167W | Carbon Film |
This table highlights the superior power rating of the CFR-50JB-52-1M, making it a reliable choice for demanding applications.
Power rating and temperature coefficient
The CFR-50JB-52-1M has a power rating of 0.5W, which allows it to handle moderate electrical loads without overheating. Its temperature coefficient ensures stable performance across a wide range of temperatures. This feature is particularly useful when you need dependable operation in environments with fluctuating thermal conditions.
Dimensions and operating temperature range
This resistor features a compact design, making it suitable for space-constrained applications. It operates efficiently within a temperature range of -55°C to +155°C. This broad range ensures that you can use it in both standard and extreme environments without compromising performance.
Tip: The CFR-50JB-52-1M’s combination of size, power rating, and temperature tolerance makes it a versatile component for various electronic projects.
Key Features of the CFR-50JB-52-1M
Reliable carbon film construction
The CFR-50JB-52-1M uses a dependable carbon film construction. This design ensures consistent electrical performance in your circuits. Carbon film resistors are known for their ability to provide stable resistance values over time. You can trust this component to maintain its integrity, even in demanding applications. Its construction also minimizes noise, which is essential for sensitive electronic systems. This feature makes it a preferred choice for audio equipment and precision instruments.
Durability and performance under varying conditions
This resistor stands out for its durability. It performs reliably under a wide range of environmental conditions. Whether you are working in high-temperature settings or cold environments, the CFR-50JB-52-1M delivers consistent results. Its ability to withstand thermal and electrical stress ensures long-term reliability. You can use it in applications where components face frequent temperature changes or electrical surges. This resilience reduces the need for frequent replacements, saving you time and resources.
Compatibility with through-hole mounting systems
The CFR-50JB-52-1M is designed for through-hole mounting systems. This compatibility makes it easy to integrate into your circuit boards. Through-hole mounting provides a secure connection, ensuring the resistor stays in place during operation. This feature is especially useful for projects requiring robust mechanical stability. You can use this resistor in both prototyping and mass production, as it simplifies assembly and enhances reliability.
Note: The CFR-50JB-52-1M combines reliability, durability, and ease of use, making it a versatile choice for various electronic applications.
Applications of the CFR-50JB-52-1M
Common industries and sectors
You will find the CFR-50JB-52-1M widely used across multiple industries. It plays a crucial role in consumer electronics, automotive systems, and industrial equipment. In consumer electronics, it supports devices like televisions, computers, and smartphones. Automotive manufacturers rely on it for its ability to handle temperature variations and electrical stress. Industrial sectors use it in machinery and control systems where reliability is essential. Its versatility makes it a valuable component in both small-scale and large-scale applications.
Specific use cases in electronic circuits
The CFR-50JB-52-1M serves several specific purposes in electronic circuits.
- It regulates voltage in computers, ensuring stable operation.
- It limits current in televisions, protecting sensitive components.
- It conditions signals in smartphones, improving performance.
- It senses temperature in automotive systems, enhancing safety.
- It performs various electronic functions in industrial equipment.
These use cases highlight its adaptability and importance in modern technology.
Examples of successful implementations
You can see the CFR-50JB-52-1M in action in many successful projects. Engineers have used it in designing efficient power supplies for computers. Automotive manufacturers have integrated it into engine control units to improve reliability. In industrial automation, it has proven effective in maintaining consistent performance under harsh conditions. Its role in these implementations demonstrates its ability to meet the demands of diverse applications.
Tip: When selecting components for your project, consider the CFR-50JB-52-1M for its proven track record in various industries.
Benefits of Using the CFR-50JB-52-1M
Cost-effectiveness for large-scale projects
The CFR-50JB-52-1M offers excellent value for large-scale projects. Its combination of affordability and performance makes it a preferred choice for manufacturers and engineers. When compared to other resistors, such as the FMP-50JB-52-1M, the CFR-50JB-52-1M provides similar power ratings and resistance at a lower cost. This balance of quality and price ensures you can optimize your budget without compromising on reliability.
| Part Number | Manufacturer | Resistance | Tolerance | Power (Watts) | Composition | Package / Case | Size / Dimension |
|---|---|---|---|---|---|---|---|
| CFR-50JB-52-1M | Yageo | 1 MΩ | ±5% | 0.5W, 1/2W | Carbon Film | Axial | 0.075 Dia x 0.134 L (1.90mm x 3.40mm) |
| FMP-50JB-52-1M | Yageo | 1 MΩ | ±5% | 0.5W, 1/2W | Metal Film | Axial | 0.075 Dia x 0.134 L (1.90mm x 3.40mm) |
This table highlights how the CFR-50JB-52-1M delivers cost-effectiveness while maintaining high performance, making it ideal for bulk purchases in industries like consumer electronics and automotive manufacturing.
Enhanced performance in precision applications
You can rely on the CFR-50JB-52-1M for precision applications. Its ±5% tolerance ensures consistent resistance, which is crucial for circuits requiring accuracy. The carbon film construction minimizes noise, making it suitable for audio equipment and sensitive instruments. Its ability to handle moderate power loads without overheating further enhances its performance. Whether you are designing a power supply or a signal conditioning circuit, this resistor ensures stable and precise operation.
Long-term reliability and value
The CFR-50JB-52-1M provides long-term reliability, reducing the need for frequent replacements. Its durable carbon film construction withstands thermal and electrical stress, ensuring consistent performance over time. This reliability translates into long-term value for your projects. By choosing this resistor, you can minimize maintenance costs and enhance the lifespan of your electronic systems. Its proven track record in demanding environments, such as automotive and industrial applications, underscores its dependability.
Tip: Investing in reliable components like the CFR-50JB-52-1M can save you time and resources in the long run.
Purchasing Information for the CFR-50JB-52-1M
Trusted distributors and online platforms
You can purchase the CFR-50JB-52-1M from several trusted distributors and online platforms. Popular options include Digi-Key, Mouser Electronics, and Newark. These platforms offer detailed product descriptions, datasheets, and customer reviews to help you make informed decisions. For bulk orders, you might consider contacting authorized distributors directly. Many of these distributors also provide discounts for large-scale purchases, making them ideal for industrial or manufacturing needs.
Tip: Always verify the authenticity of the distributor to ensure you receive genuine YAGEO products.
Pricing range and availability
The CFR-50JB-52-1M is widely available, making it easy to source for your projects. Pricing typically ranges from $0.05 to $0.15 per unit, depending on the quantity and supplier. Bulk orders often come with significant discounts, reducing the cost per unit. Availability is generally high, but demand can fluctuate based on industry trends. Checking stock levels on platforms like Digi-Key or Mouser can help you plan your purchases effectively.
Note: Ordering in advance ensures you avoid delays caused by unexpected stock shortages.
Warranty and customer support options
YAGEO and its distributors provide reliable warranty and customer support options for the CFR-50JB-52-1M. You can reach out to customer service through multiple channels for assistance.
| Contact Method | Details |
|---|---|
| service@htelec.com | |
| Telephone | +852 62639182 |
| Skype | live:.cid.b9578723a33ec6de |
| ! |
These options ensure you receive prompt support for any issues or inquiries. Most distributors also offer return or replacement policies, giving you peace of mind when purchasing.
Tip: Keep your purchase receipt and product details handy when contacting customer support for faster resolution.
The CFR-50JB-52-1M combines precision, durability, and cost-effectiveness, making it a reliable choice for your electronic projects. Its features ensure exceptional performance across industries.
| Feature | Description |
|---|---|
| AEC-Q200 qualified | Ensures reliability in automotive applications |
| Wide resistance range | Offers versatility for various electronic needs |
| High stability | Maintains performance under varying conditions |
| RoHS compliant | Meets environmental regulations |
| Halogen-free composition | Reduces harmful substances in manufacturing |
Explore trusted distributors to add this versatile component to your designs today!
FAQ
What makes the CFR-50JB-52-1M different from other resistors?
The CFR-50JB-52-1M stands out for its carbon film construction, 0.5W power rating, and wide temperature range. These features ensure durability and consistent performance in demanding applications.
Can you use the CFR-50JB-52-1M in high-temperature environments?
Yes, you can. This resistor operates efficiently between -55°C and +155°C. Its design ensures reliable performance even in extreme thermal conditions.
Where can you buy the CFR-50JB-52-1M?
You can purchase it from trusted platforms like Digi-Key, Mouser Electronics, and Newark. These distributors offer genuine products, detailed datasheets, and bulk order discounts.
Tip: Always verify the distributor's authenticity to avoid counterfeit components.
