What are the product standards of CFR-50JB-52-1K3?
The CFR-50JB-52-1K3 is a carbon film resistor designed to deliver precise resistance values and stable performance. Its construction features axial leads for easy installation and a wide operating temperature range of -55°C to 155°C. These product standards ensure reliability across diverse applications, including automotive systems, industrial equipment, and household electronics.
Key Takeaways
- The CFR-50JB-52-1K3 resistor works well in temperatures from -55°C to 155°C. This makes it useful in many different places.
- This resistor follows AEC-Q200 rules, proving it is dependable for cars in tough conditions.
- Its carbon film build makes it strong and gives exact resistance. This makes it a good and affordable option for circuits.
Detailed Product Standards
Key Specifications of CFR-50JB-52-1K3
The CFR-50JB-52-1K3 resistor adheres to precise product standards, ensuring consistent performance and reliability. Its resistance value is 1.3 kOhms, with a tolerance of ±5%, making it suitable for applications requiring moderate precision. The resistor operates efficiently within a temperature range of -55°C to 155°C, supported by a temperature coefficient of -350/+500 ppm/°C. This specification ensures stability under varying environmental conditions.
The power rating of 0.5W (1/2W) allows the resistor to handle moderate electrical loads without compromising performance. The carbon film composition enhances its durability and resistance to wear, making it a preferred choice for general electronics, industrial equipment, and automotive systems.
| Specification | Value |
|---|---|
| Resistance (Ohms) | 1.3k |
| Tolerance | ±5% |
| Temperature Coefficient | -350/+500 ppm/°C |
| Power Rating (Watts) | 0.5W (1/2W) |
| Operating Temperature | -55°C ~ 155°C |
| Composition | Carbon Film |
Dimensions, Tolerances, and Resistance Value
The CFR-50JB-52-1K3 features compact dimensions, measuring 0.130 inches in diameter and 0.354 inches in length (3.30mm x 9.00mm). This small size facilitates easy integration into circuit designs with limited space. The resistor maintains a tolerance of ±5%, ensuring that its resistance value remains within acceptable limits for most applications.
| Dimension | Tolerance |
|---|---|
| 0.130" Dia x 0.354" L | ±5% |
The resistance value of 1.3 kOhms, combined with its tolerance, makes this resistor ideal for circuits requiring moderate resistance levels. These attributes align with industry product standards, ensuring compatibility with a wide range of devices.
| Resistance Value | Tolerance |
|---|---|
| 1.3 kOhms | ±5% |
Material Properties and Power Rating
The carbon film construction of the CFR-50JB-52-1K3 provides excellent thermal stability and resistance to environmental stress. This material choice ensures long-term reliability, even in demanding conditions. The resistor's power rating of 0.5W (1/2W) allows it to dissipate heat effectively, reducing the risk of overheating during operation.
| Component | Material |
|---|---|
| CFR-50JB-52-1K3 | Carbon Film |
The combination of robust material properties and a reliable power rating makes this resistor a versatile component for various applications. Its adherence to strict product standards ensures consistent performance across diverse environments.
Compliance and Certifications
AEC-Q200 Compliance for Automotive Applications
The CFR-50JB-52-1K3 resistor meets the stringent AEC-Q200 standards, making it suitable for automotive applications. These standards ensure that the resistor can withstand the demanding conditions often encountered in automotive environments, such as extreme temperatures, vibrations, and electrical stress. By adhering to AEC-Q200, the resistor guarantees reliability and durability, which are critical for automotive systems. This compliance also enhances its appeal to manufacturers seeking components that meet industry-recognized benchmarks for quality and performance.
RoHS and Environmental Safety Standards
The CFR-50JB-52-1K3 complies with the Restriction of Hazardous Substances (RoHS) directive, aligning with EU Directive 2011/65/EC. This certification ensures that the resistor contains less than 0.1% lead by weight in its termination material, making it environmentally friendly and safe for use in various applications. The following table highlights its compliance status:
| Certification Type | Compliance Status |
|---|---|
| Lead Free | Pb Free |
| RoHS | Yes |
Additionally, the resistor's adherence to environmental safety standards reflects its commitment to reducing hazardous materials in electronic components. This compliance supports global efforts to minimize environmental impact while maintaining high product standards.
Moisture Sensitivity and Operating Temperature Range
The CFR-50JB-52-1K3 exhibits a moisture sensitivity level (MSL) of 1, indicating unlimited floor life under standard conditions. This characteristic ensures that the resistor remains stable and functional even in humid environments. The table below summarizes its moisture sensitivity:
| Parameter | Value |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
The resistor also operates efficiently within a temperature range of -55°C to 155°C. This wide range allows it to perform reliably in both extreme cold and high-heat conditions, making it suitable for diverse applications. These attributes further reinforce its reputation as a dependable component that adheres to rigorous product standards.
Applications and Use Cases
Industries Utilizing CFR-50JB-52-1K3
The CFR-50JB-52-1K3 resistor finds applications across multiple industries due to its reliable performance and adherence to strict product standards. Its versatility makes it a preferred choice for professionals in the following sectors:
| Industry |
|---|
| General electronics |
| Industrial equipment |
| Automotive applications |
| Household appliances |
These industries benefit from the resistor's durability, precision, and ability to operate under varying environmental conditions. Its compatibility with diverse systems ensures widespread adoption in both commercial and industrial settings.
Common Use Cases in Electronics and Automotive
The CFR-50JB-52-1K3 serves as a critical component in numerous applications. Its robust design and consistent performance make it suitable for the following areas:
| Application Area |
|---|
| General electronics |
| Industrial equipment |
| Automotive applications |
| Household appliances |
In automotive systems, it supports functions like voltage regulation and signal processing. In household appliances, it ensures stable operation in devices such as washing machines and microwaves. Its role in industrial equipment includes managing electrical loads and protecting circuits from fluctuations.
Advantages of Using CFR-50JB-52-1K3 in Circuits
The CFR-50JB-52-1K3 offers several advantages that enhance its appeal for circuit design. These benefits include:
| Advantage | Description |
|---|---|
| Temperature Stability | Excellent temperature stability with a coefficient of -500/+350ppm/°C |
| Construction Reliability | Reliable and durable construction for long-lasting performance |
| Cost-Effectiveness | Cost-effective solution for budget-conscious projects |
| Resistance Value Precision | Carbon film construction for precise resistance value and stability |
| Installation Ease | Axial lead configuration for easy installation |
| Operating Temperature Range | Wide operating temperature range of -55°C to 155°C |
| Tolerance | ±5% tolerance for tight resistance control |
These features ensure the resistor performs consistently in demanding environments. Its precise resistance value and ease of installation make it a practical choice for engineers and designers. The wide operating temperature range further enhances its suitability for applications requiring high reliability.
The CFR-50JB-52-1K3 exemplifies high-quality product standards, ensuring reliability and precision in various applications. Its compliance with AEC-Q200 and RoHS certifications highlights its suitability for automotive and environmentally conscious industries. Understanding these standards enables engineers to optimize performance and maintain compliance, making this resistor a dependable choice for diverse circuit designs.
FAQ
What makes the CFR-50JB-52-1K3 suitable for automotive applications?
The CFR-50JB-52-1K3 meets AEC-Q200 standards, ensuring durability under extreme temperatures, vibrations, and electrical stress. Its reliability makes it ideal for automotive systems.
How does the resistor comply with environmental safety standards?
The resistor adheres to RoHS directives, limiting hazardous substances like lead. This compliance ensures environmental safety and aligns with global sustainability efforts.
Can the CFR-50JB-52-1K3 operate in humid conditions?
Yes, the resistor has a moisture sensitivity level (MSL) of 1, offering unlimited floor life under standard conditions. It performs reliably even in humid environments.
